In the fields of high-temperature refractories, ceramic binders, anti-corrosion coatings, and electrical insulation materials, Aluminium Dihydrogen Phosphate (ADP) is an irreplaceable inorganic binder.
However, in practical applications, companies often face a fundamental yet critical question:
Should I choose solid ADP powder or liquid ADP solution?
This article combines recent advancements in materials science (including the latest findings on low-temperature curing phosphate coatings published in the Journal of Surface Technology, 2026) and provides a systematic comparison of the two forms across four dimensions: performance, cost, processing, and application scenarios. It aims to help engineers and procurement professionals make more informed technical decisions.
Aluminium Dihydrogen Phosphate is an odorless, tasteless, and non-toxic inorganic compound with the typical chemical formula Al(H₂PO₄)₃. Its core characteristics include:
High-temperature bonding strength
Good chemical stability
High compatibility with metals, ceramics, and refractory aggregates
Forms a water-resistant and weather-resistant network structure after heating
Based on production and supply forms, ADP is mainly divided into:
Liquid ADP (aqueous solution, typically 50%–70% solid content)
Solid ADP (spray-dried powder)
| Parameter | Liquid ADP | Solid ADP (Spray-Dried) |
|---|---|---|
| Form | Viscous transparent liquid | White powder |
| Production process | Direct formulation after neutralization reaction | Requires additional spray drying |
| Unit cost | Relatively lower | Significantly higher |
| Transport cost | Higher (heavy, requires freeze protection) | Lower |
| Storage requirements | Sealed, anti-crystallization, anti-freeze | Dry and moisture-proof |
| On-site use | Ready to use or dilute | Requires dissolution in water or liquid binder |
Curing temperature: typically 350–500°C
Forms a dense P–O–Al three-dimensional network after heat treatment
Excellent hydration resistance; does not soften even when boiled in water
Suitable for:
High-temperature kiln linings
Refractory bricks and ramming mixes
Environments requiring long-term water or湿热 (heat-humidity) resistance
Good low-temperature / room-temperature curing capability
Recent studies show curing at as low as 200°C via dehydration condensation
Bond strength to concrete and ceramic substrates > 5 MPa
Suitable for:
Coatings on large workpieces
On-site repairs and spray applications
Scenarios where high-temperature baking is not possible
Recent research has found that ADP is not only a binder but also an ideal base material for high-performance gas barrier coatings.
By adding fillers such as alumina or silica to liquid ADP, a dense protective layer can be prepared with gas permeability as low as:
6.89 × 10⁻¹⁸ m²
This dense coating offers significant advantages in high-temperature anti-oxidation and media permeation resistance, making it especially suitable for:
High-temperature metal protection
Anti-oxidation coatings for carbon materials
Electronic packaging barrier layers
This indicates that the application potential of liquid ADP in functional coatings is being re-evaluated.
On-site construction or mixing on location
Spray or brush coating on complex structures
Low-temperature curing (≤300°C) is required
Large workpieces cannot enter a high-temperature furnace
Preparing functional coatings (e.g., gas barrier, anti-corrosion)
Manufacturing standardized refractory bricks or preforms
Dry-mix materials require long-term storage
High-temperature hydration resistance is critical
Transport and warehousing costs are sensitive
Precise formula control is needed
Q1: Can solid ADP be turned into liquid ADP by simply adding water?
Yes, but attention must be paid to dissolution temperature, concentration control, and thorough mixing; otherwise, bond strength may be affected.
Q2: What happens if liquid ADP crystallizes during storage?
Mild crystallization can be reversed by heating and stirring. However, if stored too long or degraded, performance should be re-tested.
Q3: Which form is better for blast furnace tap hole mud?
Liquid ADP is typically preferred due to its better fluidity and adhesion, which facilitates on-site construction.
Q4: Can the two forms be mixed together?
Yes. Some formulations use both solid and liquid ADP to balance processability and high-temperature performance.
Solid and liquid Aluminium Dihydrogen Phosphate are not about which is better — they are about different application scenarios.
Solid ADP = high-temperature stability, convenient storage & transport, suitable for standardized manufacturing
Liquid ADP = flexible construction, low-temperature curing, suitable for coatings and on-site work
In actual engineering projects, it is recommended to evaluate based on four dimensions: curing temperature, process conditions, cost structure, and storage cycle.
